Direct answer

Choose an internal puller collet by the bearing bore, not the outside diameter. The correct collet expands inside the bore with enough contact depth to grip securely, while remaining within its specified expansion range and compatible with the puller bridge or slide hammer.

Measure the bearing bore first

Clean the bore and measure its inside diameter with a suitable gauge or caliper. Compare that measurement with the collet's working range, not simply the nominal size printed on the case.

Motorcycle workshop setting where compact internal bearing access is common

Stay within the collet expansion range

A collet needs room to expand and lock against the bore. Selecting one at the extreme end of its range can reduce contact and increase the chance of slipping under load.

Use a collet whose stated range includes the measured bore.
Avoid forcing an undersized collet to expand beyond its limit.
Avoid an oversized collet that cannot contact the bore evenly.

Precision machine equipment illustrating diameter and alignment checks

Check engagement depth

The collet must reach far enough into the bearing or race to expand behind a sound internal surface. Shallow engagement can pull on a chamfer or damaged edge instead of the intended bore wall.

Technician working on compact mechanical equipment in a service workshop

Match the collet to the puller system

Confirm the thread, adapter, bridge, or slide-hammer connection before beginning. A correctly sized collet still needs a compatible extraction tool that keeps force centered.

Inspect bore condition before pulling

Rust, burrs, or a broken race can prevent even contact. Clean loose debris and reassess the tool choice if the bore is damaged enough that the collet cannot expand uniformly.

Use a bridge when straight pull control matters

A bridge and forcing screw can keep the pull more axial than a slide hammer. This is useful when the housing edge is delicate or the bearing is seated deeply in a blind bore.

Test the grip at low load

Apply light tension first, then verify that the collet remains seated and the puller is aligned. If it shifts, release force and choose a better size or a different removal method.

Keep a practical collet range on hand

Workshops servicing varied bore sizes benefit from a complete, labeled collet set. DNT Tools can help align a collet range with the common bearing bores and extractor connections in your work.

When to stop and ask for support

Stop if the tool starts to tilt, the grip moves off the intended bearing surface, the forcing screw binds, or the required force is uncertain. A DNT Tools support discussion can help match the puller, separator, collet, and adapters to the job.
